TerraForce GEN2 Offset 48 plate folding
TerraForce GEN2 Offset 48 plate folding
Terraforce
powerful tillage - when you need it
Take the next step up to serious tillage with the second generation of TerraForce and TerraForceX. The GEN2 models have a range of new features to get the job done.
Both models have 200mm x 200mm x 12mm fully gusseted main frame with extra diagonal cross members... these machine are one serious bit of kit.
TerraForce:
710mm (28") x 8mm boron discs
250mm (10") disc spacings
55mm gang axles
TerraForceX:
810mm (32") x 12mm boron discs
300mm (12") disc spacings
65mm gang axles
All TerraForce offsets come with HydraJust (Patent Pending), allowing easy adjustment of plowing aggression in minutes.
Both models come standard with solid/puncture-proof 385/65 R22.5 tyres or the option of 600/50 R22.5 flotation tyres
Other features include
Double bearings in a steel grease bath housing
Adjustable scrapers
Extra filler disc
Axle & pitch spanners
2 pack paint
The TerraForce and TerraForceX comes in a range of disc configurations, as well as several folding options
Hydra-Just (hydraulic gang adjustment)
Change the angle of your plow gangs with ease with our hydraulic gang adjustment. Whether you set the angle wide for aggressive deep digging or go narrow angle for a shallower cut, with Hydra-Just, changing the gang angle is simple!
New Features:
-Twin spring pitch adjustment w/level gauge
-Hydraulic drawbar adjustment (to adjust for crabbing)
-Adjustable ball hitch to allow for uneven ground
-Burst valves on wheel cylinders
-Plow depth gauge
-Electric over hydraulic control with in cab controller for folding machines
-Square rear frame to allow for cost effective fitting of crumble rollers and seeders
-Rear tow hitch
-Tool box
-Gang nut locks
Discs | Working width | Hp Required | Weight | Disc size | Axles | Price (ex GST) |
|---|---|---|---|---|---|---|
24 | 3m | 130-140 | 3,940kg | 28" x 8mm | 55mm | $22,900 |
28 | 3.5m | 140-150 | 4,320kg | 28" x 8mm | 55mm | $25,900 |
32 | 4m | 150-170 | 4,950kg | 28" x 8mm | 55mm | $27,950 |
36 | 4.5m | 160-180 | 5,150kg | 28" x 8mm | 55mm | $29,980 |
40 | 5m | 170-190 | 5,400kg | 28" x 8mm | 55mm | $32,450 |
44 | 5.5m | 190-210 | 5,850kg | 28" x 8mm | 55mm | $34,975 |
48 | 6m | 210-230 | 6,330kg | 28" x 8mm | 55mm | $37,900 |
40 (folding) | 5m | 180-200 | 6,480kg | 28" x 8mm | 55mm | $38,650 |
44 (folding) | 5.5m | 200-220 | 6,960kg | 28" x 8mm | 55mm | $40,800 |
48 (folding) | 6m | 220-240 | 7,440kg | 28" x 8mm | 55mm | $43,350 |
Prices exclude GST. Prices do not include delivery charges or setup
Discs | Working width | Hp Required | Weight | Disc size | Axles | Price (ex GST) |
|---|---|---|---|---|---|---|
24 | 3.7m | 150-160 | 6,600kg | 32" x 12mm | 65mm | $32,200 |
28 | 4.3m | 160-180 | 7,400kg | 32" x 12mm | 65mm | $36,900 |
32 | 4.8m | 180-200 | 8,100kg | 32" x 12mm | 65mm | $39,700 |
36 | 5.4m | 200-220 | 8,600kg | 32" x 12mm | 65mm | $43,250 |
40 | 6m | 220-240 | 9,100kg | 32" x 12mm | 65mm | $47,250 |
40 (Folding) | 6m | 230-250 | 9,500kg | 32" x 12mm | 65mm | $512,950 |
44 (folding) | 6.6m | 250-280 | 9,700kg | 32" x 12mm | 65mm | $56,400 |
48 (folding) | 7.2m | 280-310 | 9,900kg | 32" x 12mm | 65mm | $59,700 |
Prices exclude GST. Prices do not include delivery charges or setup
Options for both the TerraForce and TerraForceX
-Wheel equipment options:
385/65 R22.5 solid tyres (standard)
-or-
600/50 R22.5 floatation tyres
-Hydraulic crumble roller
-Drum seeder
-10.5" or 12" disc spacings (standard 12")
-Oversize sign/light kit
-Choose your own colour for machine
-Reverse gang orientation
-Sand spacers (narrow diameter spacers for sandy soil/deeper tillage)
Compare the Metis TerraNova to other brands on the market. Just choose the disc configuration below to view the data
Specs | Metis TerraForce | Metis TerraForceX | Baldan GTCR | Big Country Mega | Serafin Eco Grande | Serafin Eco Busta | Tatu GCRO 7012 | Welch Extra HD |
|---|---|---|---|---|---|---|---|---|
Number of discs | 28 | 28 | 30 | 28 | 28 | 28 | 28 | 28 |
Working width | 3.5m | 4.3m | 4.93m | 4.1m | 3.7m | 4.4m | 3.9m | 4.1m |
Disc size | 28" x 8mm | 32" x 12mm | 32" x 9mm | 32" x 10mm | 28" x 7.5mm | 32" x 8mm | 32" x 9mm | 32" x 12mm |
Disc spacing (mm) | 250 | 300 | 340 | 300 | 270 | 340 | 300 | 300 |
Weight (kg) | 4400 | 7400 | 5112 | 6780 | 3550 | 5800 | 5700 | 7100 |
Weight per disc (kg) | 157 | 264 | 170 | 242 | 127 | 207 | 204 | 254 |
Disc axle size (mm) | 55 | 65 | 60 | 55 | 40 | 60 | 55 | 65 |
Frame size (mm) | 200 x 200 x 12 | 200 x 200 x 12 | TBC | 200 x 150 x 10 | 200 x 150 x 10 | 200 x 150 x 10 | TBC | 200 x 200 x 12 |
Frame strength (kg/m) | 71.5 | 71.5 | TBC | 52.3 | 52.3 | 52.3 | TBC | 71.5 |
Hydraulic gang adjust | YES | YES | NO | NO | NO | NO | NO | NO |
Hydraulic pitch control | YES | YES | NO | NO | NO | NO | YES | YES |
Pitch level gauge | YES | YES | NO | NO | NO | NO | NO | NO |
Upgrade to solid tyres | YES | YES | NO | NO | NO | NO | NO | YES |
Extra helper disc | YES | YES | NO | NO | NO | NO | YES | YES |
Axle and pitch spanner | YES | YES | NO | NO | NO | NO | NO | NO |
Extra frame bracing | YES | YES | YES | NO | NO | NO | NO | NO |
Hydraulic adjust drawbar | YES | YES | NO | NO | NO | NO | NO | NO |
Wheel cylinder burst valves | YES | YES | NO | NO | NO | NO | NO | NO |
Plow depth gauge | YES | YES | NO | NO | NO | NO | NO | NO |
Price (ex GST) | $25,900 | $36,900 | $60,000 | $38,000 | $25,300 | $36,100 | $78,000 | $34,160 |
NOTE: Competitor specifications and pricing sourced from their websites and listing agents and is correct at time of publication (10/04/26)
