terratitan
designed for extreme tillage work
Metis TerraTitan offset discs are the workhorse offsets in our range.
The TerraTitan X has the upgraded 250mm x 250mm x 20mm frame and larger (36") discs than the standard TerraTitan.
The TerraTitan Xtreme also has the upgraded 250mm x 250mm x 20mm frame, with huge 40" discs for the toughest conditions
Designed to work new country and suckers achieving depths of 300mm plus.
You can rest easy with our 12 month warranty on all new Metis implements. We also have a extensive range of spare parts in stock to get you out of trouble.
Discs | Working width | Hp Required | Disc size | Weight | Axles | Price |
|---|---|---|---|---|---|---|
24 | 3.6m | 200-240 | 36" x 12mm | 9,100kg | 65mm | $58,700 |
28 | 4.2m | 240-280 | 36" x 12mm | 10,100kg | 65mm | $66,400 |
32 | 4.8m | 280-320 | 36" x 12mm | 11,500kg | 65mm | $75,000 |
40 | 6m | 320+ | 36" x 12mm | 12,490kg | 65mm | $90,000 |
Prices exclude GST. Prices do not include delivery charges or setup
Discs | Working width | Hp Required | Weight | Disc size | Axles | Price |
|---|---|---|---|---|---|---|
24 | 3.6m | 230-260 | 12,000kg | 38" x 16mm | 100mm | $68,250 |
28 | 4.2m | 260-290 | 12,950kg | 38" x 16mm | 100mm | $77,000 |
32 | 4.8m | 290-320 | 14,600kg | 38" x 16mm | 100mm | $87,250 |
40 | 6m | 320+ | 16,100kg | 38" x 16mm | 100mm | $99,950 |
Prices exclude GST. Prices do not include delivery charges or setup
